中文CA200 series servo drive
CA200 series servo drive is an economical servo drive unit, integrating various intellectual control theories, rapid current response, humanity operation method and parameter design. It reduces the technical requirements for the users and decreases the difficulty to match with upper system.
Based on a new software and hardware platform., CA200 could be suit for various industrial area with flexible extended function and ensure high performance-price ratio.
Typical applications
-Machine tool
-Engraving machine
-Textile equipment
-Packaging machinery
-Cutting machine
-Food processing
-Speed loop response bandwidth 1.2kHz, setting time is sharply reduced compared with others
-Max 23bit absolute encoder, position accuracy±1 pulse, reliable performance at low speed
-Available Ethercat bus, transmission ratio 100Mbps, support 1ms synchronous period
-Standard double RJ45 terminal to achieve industrial Ethercat response connection.
-Automatic inertia identification and gain adjustment, shorten servo adjustment time
-Standard 17bit absolute bit, 20bit incremental and 23 bit available,
-Standard oil-sealed design, the motor protection degree IP65
